Description
5 m of black powder-coated long span shelving, 2.4 m high and 600 mm deep, rated to 3600 kg across 3 bays. This is the BS2460 — an extra-large bracket plate and re-cut upright holes, so the beams clip in squarely and stay put.
How the run is made up
- 3 bays — 1.5 m + 1.5 m + 2 m
- Four adjustable shelf levels in every bay
- 4 upright frames — one more than the number of bays, because neighbouring bays share one
- Beams 1.5 m and 2 m, one pair per level
- Shelf panels 0.75 m × 600 mm and 1 m × 600 mm, two per level
Because the bays share their uprights, the finished run measures a little under 5 m rather than exactly 5 m. Worth knowing if you are fitting it between two walls.
How to read the load rating
1200 kg is the rating for one bay, so 3600 kg for the 3 bays together, with the weight spread evenly across all four levels. Concentrating a load on one level, or in the middle of a span, is a different question — tell us what you are storing and we will give you the figure for it.
Why this one
The BS2460 sits between the garage shelving most people buy and a warehouse rack: black powder coat rather than blue, a deeper bracket, and enough capacity for engine parts, full toolboxes and pallet-weight loads without going to pallet racking. Compare it against anything of its type before you buy — the bracket and the upright are where the difference is, and both are visible in the photographs.
Extra levels are sold separately in 1.5 m and 2 m to match this unit, and bays can be added to either end later.
